How To Change Rear Brake Shoes On Suzuki Grand Vitara

By | February 17, 2022



Changing rear brake shoes on your Suzuki Grand Vitara can be a daunting task for even the most experienced DIY-ers. But with the right tools and a bit of know-how, you can save yourself time and money by getting the job done yourself. In this article, we’ll walk you through the steps of changing your rear brake shoes on your Suzuki Grand Vitara so that you can get back out on the road quickly and safely.

The first step in changing your rear brake shoes on your Suzuki Grand Vitara is to make sure you have all the necessary tools on hand. You’ll need a lug wrench or socket set, a jack and jack stands, a pry bar, a hammer, and a C-clamp. It’s also helpful to have a mechanic’s stethoscope or a flashlight to help diagnose any potential issues.

Once you have all the required tools, you can begin the process of changing your rear brake shoes. Start by jacking up your Suzuki Grand Vitara and placing jack stands under it for support. Once the vehicle is secure, you can remove the wheel and tire from the rear of the vehicle. Now you can access the brake drum and remove the two bolts that hold the drum in place. Once the drum is off, you can remove the old brake shoes and springs.

Next, you’ll need to install the new brake shoes and springs. Begin by pushing the new brake shoes onto the axle and securing them with the retaining clip. Now you can attach the springs to the brake shoes and make sure they are properly secured. Once the springs are in place, you can replace the drum, making sure the axle and brake shoes are in the correct alignment. Once the drum is in place, you can reinstall the wheel and tire and lower the vehicle.

Finally, you’ll need to check the brakes for proper functioning. Pump the brakes a few times to ensure they are working correctly. If everything looks good, you’re ready to hit the road again.

Changing the rear brake shoes on your Suzuki Grand Vitara is not a difficult task, and with the right tools and a bit of know-how, you can complete the job successfully. Just make sure you have all the necessary tools on hand and take your time to ensure that everything is installed correctly. Once you’ve gone through the process, you can enjoy the peace of mind that comes with knowing you’ve taken care of the brakes on your vehicle.
